Socket-Weld Flanges has a female socket in which pipe is fitted. Fillet welding is done from outside on the pipe. The socket welding flange is similar to a slip-on flange except it has a bore and a counterbore dimension.

Titanium Socket Weld flanges were initially developed for use on small-size high pressure piping. Their static strength is equal to Slip On flanges, but their fatigue strength 50% greater than double-welded Slip On flanges. The connection with the pipe is done with 1 fillet weld, at the outside of the flange. But before welding, a space must be created between flange or fitting and pipe.

The purpose for the bottoming clearance in a Socket Weld is usually to reduce the residual stress at the root of the weld that could occur during solidification of the weld metal. The image shows you the X measure for the expansion gap.

The disadvantage of this flange is right the gap, that must be made. By corrosive products, and mainly in stainless steel pipe systems, the crack between pipe and flange can give corrosion problems. In some processes this flange is also not allowed. Also for this flange counts, that principle always firstly a pipe must be welded and then just a fitting.

Titanium Socket weld pipe flanges are used in the applications where there are smaller sizes of high pressure pipes used. These pipe flanges are attached by inserting the pipe into the socket end and applying fillet weld around the top. This helps in better flowing of the fluid or gas inside the pipe. These socket weld pipe flange is available in all materials, sizes and specifications.

B16.5 ASTM A182 Socket Weld Flange, Fusion Bonded Epoxy Coating, EN 1092-2 PN16 Socket Weld Flange, ASME B16.5 Dual Titanium Alloy Socket Weld Flange, ANSI B16.5 Class 150 Flat Face Socket Weld Flange, Titanium Alloy Gr.2 (3.7035) / Gr.3:(3.7055) 30 Inch Socket Weld Flange Stockiest.


Standards Specification:

  • Size : 1/2" to 48"
  • Specifications : ASTM A182
  • Rating: 150#, 300#, 600 (2.4640)#, 900#, 1500#, 2500#,

Material & Grade :

Titanium :
Grade: Gr.1 (3.7025) , Gr.2 (3.7035) , Gr.3:(3.7055) , Gr.5(3.7164/65), Gr. 7(3.7235) , Gr. 11 (3.7225)

Chemical Composition

C Fe H N O Ti
max max max max max max
0.1 0.2 0.015 0.03 0.18 99.5

Mechanical Properties

Hardness, Brinell 120120 annealed
Hardness, Knoop132132 Estimated from Brinell.
Hardness, Rockwell B7070 annealed
Hardness, Vickers122122 Estimated from Brinell.
Tensile Strength, Ultimate240 MPa34800 psi
Tensile Strength, Yield170 - 310 MPa24700 - 45000 psi
Elongation at Break24 %24 %
Reduction of Area35 %35 %
Modulus of Elasticity105 GPa15200 ksi In Tension
Compressive Modulus110 GPa16000 ksi
Poisson's Ratio0.370.37
Charpy Impact310 J229 ft-lb V-notch
Shear Modulus45 GPa6530 ksi
